STAHLWERK ARC 200 MD Digital welding machine with 200 amps | fully equipped | welding helmet | electrodes | equipment trolley | DC MMA/E-Hand | Lift-TIG | digital display | ARC-Force | VRD | smart cooling

STAHLWERK ARC 200 MD Digital welding machine with 200 amps | fully equipped | welding helmet | electrodes | equipment trolley | DC MMA/E-Hand | Lift-TIG | digital display | ARC-Force | VRD | smart cooling

SKU: 8123
GTIN: 4262553781232
Category: ARC MMA welding machines

The STAHLWERK ARC 200 MD Digital is a particularly compact and lightweight DC electrode welder for universal MMA/E manual welding. With a welding current range of 10-200 A, it covers numerous applications in the repair, assembly and workshop sectors. Thanks to its single-board design and the latest generation of IGBT technology, the device delivers stable welding currents with high thermal stability. The set welding parameters can be conveniently read off the clear digital display. Hotstart, Anti-Stick and ARC-Force ensure a clean start and a stable process: Hotstart supports ignition, Anti-Stick prevents the electrode from sticking by automatically lowering the current and ARC-Force stabilizes the arc with short arc lengths and increases penetration - particularly helpful with cellulose and alkaline electrodes. In addition, the VRD function (Voltage Reduction Device) can be activated manually to reduce the output voltage to a safe level when idle, as long as no welding is taking place. The reference current function can be used to select a recommended current (material thickness 1.0-10.0 mm and electrode diameter 1.6-5.0 mm). The device then automatically sets the appropriate welding current - the function is deactivated for manual readjustment. In combination with the optionally available STAHLWERK WP-17V welding torch, the versatile inverter welding machine can be converted into a TIG welding machine with lift TIG (contact ignition) - ideal for finer work on steel and stainless steel. Smart cooling, intelligent temperature control (demand-controlled fan) and protection functions against overheating/overloading, together with the robust ST-Guard housing, ensure high operational reliability and a long service life. The tool and equipment trolley included in the scope of delivery offers space for the welding machine and many accessories.

174,99 €

incl. 19% VAT , plus

Instead of: 209,99 €

(Save 16.67%, i.e. 35,00 €)

Available immediately
Delivery time: 1 - 3 Workdays (DE - int. shipments may differ)

You can purchase a maximum of Units 3 of this item.

Manufacturer information

STAHLWERK Schweissgeräte Deutschland GmbH was founded in 1998 and offers original welding equipment as a manufacturer. We are your professional and reliable welding equipment supplier. Product safety carries the registered trademark STAHLWERK. The company responsible for product safety is STAHLWERK Schweissgeräte GmbH
located in Bornheim
Mainstraße 4
53332
Germany. For questions regarding product safety
please contact us at the electronic address info@stahlwerk-schweissgeraete.de or by phone at +49 228 24331713. The person responsible for product safety is Alexander Hamann.

To go with this article we recommend

STAHLWERK 2 x set of 4 magnetic welding brackets 4 kg | 9 lbs practical welding magnet | magnetic bracket | welding positioner with strong adhesive force

19,99 € *

STAHLWERK 2 x stick electrodes AWS E6013RR thick rutile coated 2 mm x 300 mm, welding current 50-70 A, high chemical purity, 2 kg MMA ARC.

22,99 € *

5,75 € per 1 kg

STAHLWERK set of 2 magnetic welding brackets 34 kg | 75 lbs practical welding magnet | magnetic bracket | welding positioner with strong adhesive force

16,99 € *

STAHLWERK 2x stick electrodes AWS E6013RR thick rutile coated 2.5 x 350 mm, welding current 50-90 A, high chemical purity, 2 kg MMA ARC. welding equipment offers high-quality welding

20,99 € *

5,25 € per 1 kg

STAHLWERK automatic welding helmet WORKER 3-in-1 welding helmet | welding shield | welding mask with true color true color reproduction, automatic darkening DIN 4 to DIN 13 and optical class 1/1/1/2

29,99 € *

STAHLWERK Wire brush set 220 mm (9 inch) 3-piece brush set consisting of brass brush, steel brush and nylon brush for effective surface cleaning

8,99 € *

STAHLWERK stainless steel wire brush with 4 rows

9,99 € *

STAHLWERK Holder with Magnetic Base for Welding Electrode Pliers / Electrode Pliers Holder, High Quality Painted

12,99 € *

STAHLWERK Hexagon welding magnet | Powerful magnet for versatile applications with 50 kg adhesive force Set of 2

19,99 € *

STAHLWERK Magnetic ground clamp EC-300 ST / ground clamp / ground magnet for welding equipment and plasma cutters up to 300 A

10,99 € *

Old price: ~~21,99 €~~

STAHLWERK MMA | ARC electrode holder 300 A electrode clamp | electrode tongs | welding tongs for welding electrodes

9,99 € *

Old price: ~~11,99 €~~

STAHLWERK MMA | ARC electrode holder up to 200 A welding tongs | electrode clamp for welding equipment including 5 m welding cable with 25 mm² and 9 mm plug

24,99 € *

STAHLWERK Mobile welding table AWT-930 ST 1068 x 532 mm Height-adjustable, foldable workbench | work table | assembly table with 705 - 930 mm stroke range, 450 kg load capacity and D20 perforated plate

135,99 € *

STAHLWERK fume extraction unit FE-210 ST with triple filter and 210 W extraction system | fume absorber | fume extractor | welding fume and soldering extraction unit for filtering and extracting fumes, gases and vapors

549,99 € *

STAHLWERK Slag hammer / welding hammer 300 g robust slag hammer made of steel, pointed and flat chisel with vibration-reducing handle

9,99 € *

STAHLWERK welding set | 300 g slag hammer, vibration-inhibiting with pointed and flat chisel | 4-row stainless steel wire brush | 2 kg pack of rutile-coated stick electrodes AWS E6013RR, thick, 2.5 x 350 mm

19,99 € *

STAHLWERK welding sleeves | welding gauntlets | welding sleeves | welding arm protection | welding protective clothing with elastic waistband made of high-quality split leather

19,99 € *

STAHLWERK welder's sleeves | welder's gauntlets | welder's arm protection | welder's protective clothing with Velcro fastener made of high-quality split leather for welding and plasma cutting

21,99 € *

STAHLWERK welding sleeves | welding gauntlets | welding sleeves | welding arm protection | welding protective clothing with carrying straps made of high-quality split leather

29,99 € *

STAHLWERK Welding gloves | heat protection gloves | work gloves | heat-resistant gloves made of high-quality split leather for welding and plasma cutting

19,99 € *

STAHLWERK welding gloves protective gloves work gloves robust genuine leather heat and fire resistant, white yellow, suitable for TIG TIG MIG MAG MMA plasma

21,99 € *

32,99 € *

Old price: ~~39,99 €~~

STAHLWERK welding gloves extra robust heat protection gloves | work gloves | welding gloves | heat-resistant gloves made of high-quality split leather for welding plasma cutting

21,99 € *

STAHLWERK Welding protection curtain welding protection curtain 2,4m x 1,8m, UV resistant partition wall made of high quality vinyl plastic, mobile steel frame with rollers

94,99 € *

22,99 € *

STAHLWERK welding table | assembly table with 500 kg load capacity and 3 mm worktop 91.5 x 46 x 90 cm in D16 hole system, DIY kit made of heavy-duty carbon steel with levelable stainless steel feet

145,99 € *

STAHLWERK welding table assembly table DIY kit with solid 12 mm worktop, D22 hole system, heavy-duty S355 steel, powder-coated legs, levelable stainless steel feet, load capacity up to 1.5 t

349,99 € *

STAHLWERK Welding table extension SA-500 ST 500 x 400 mm mobile welding booth | folding welding table extension for workbenches and assembly tables with D16 perforated plate for clamping tools

41,99 € *

STAHLWERK welding trolley SW-800-ST with 1.5 mm wall thickness | Longlife rubber rollers | Equipment trolley for welding equipment and plasma cutters with cable and hose holder and chain lock for gas cylinders

179,99 € *

STAHLWERK stick electrodes AWS E6013RR thick rutile coated 2 mm x 300 mm welding current 50-70 A, high chemical purity 2 kg MMA ARC

13,99 € *

STAHLWERK Stick electrodes AWS E6013RR thick rutile coated 2.5 x 350 mm welding current 50-90 A, high chemical purity 2 kg MMA ARC

12,99 € *

6,50 € per 1 kg

STAHLWERK WP-17V Universal Lift-Tig Torch / Welding Torch with 4 m Hose Package and 9 mm Mandrel

45,99 € *

STAHLWERK 2 × Magnet Welding Angle Magnet Welding Magnet 45° x 90° x 135°, 22,6 kg / 50 lbs

12,99 € *

STAHLWERK 2x stick electrodes AWS E6013RR thick rutile coated 3.2 x 350 mm, welding current 90-130 A, high chemical purity, 2 kg MMA ARC. welding equipment offers high-quality welding

20,99 € *

5,25 € per 1 kg

STAHLWERK Automatic welding helmet BOOSTER 3-in-1 welding helmet | welding mask with true color true color reproduction, job memory, automatic darkening DIN 4 to DIN 13 and optical class 1/1/1/2

54,99 € *

STAHLWERK Automatic welding helmet BULLET 3-in-1 welding helmet | welding shield | welding mask with true color true color reproduction, automatic darkening DIN 4 to DIN 13 and optical class 1/1/1/2

44,99 € *

STAHLWERK MASTER 3-in-1 automatic welding helmet with remote control, folding visor, true color true color reproduction, job memory, automatic darkening DIN 4 to DIN 14 and optical class 1/1/1/1

149,99 € *

STAHLWERK automatic welding helmet RAPTOR 3-in-1 welding mask with LED light, true color true color rendering, job memory, automatic darkening DIN 4 to DIN 13 and optical class 1/1/1/2

69,99 € *

STAHLWERK SPLIT 3-in-1 automatic welding helmet with 180° field of vision, LCD color display, true-color true-color reproduction, job memory, automatic dimming DIN 4 to DIN 14 and optical class

119,99 € *

STAHLWERK Automatic welding helmet TITAN 3-in-1 welding helmet | welding mask with true color true color reproduction, job memory, automatic darkening DIN 4 to DIN 14 and optical class 1/1/1/1

79,99 € *

STAHLWERK welder arm protectors splash guards arm sleeves welder sleeves made of heat resistant and durable genuine leather, high quality workmanship

24,99 € *

STAHLWERK Welding cap | welding helmet | welding hood | welding mask | flame-retardant protective clothing for welding and plasma cutting

19,99 € *

STAHLWERK welding table WT-960 ST 915 x 457 mm galvanized assembly table with 200 kg load capacity, D22 perforated plate, powder-coated legs and storage compartment

154,99 € *

STAHLWERK Stick electrodes AWS E6013RR thick rutile coated 3.2 x 350 mm, welding current 90-130 A, high chemical purity, 2 kg MMA ARC

12,99 € *

6,50 € per 1 kg

SALE & Special Offers

Our Performance Promise

Developed in Germany – Made for the Future!

Best Service for Customers Even After the Warranty Expires

About Us

Company

Fraunhofer Technology Day

Career

STAHLWERK TV

Sponsoring Partnerships

Social Responsibility

Service

Branches & Authorized Service Partners

Test On-Site

TÜV Rheinland Training & Welding Schools

Leasing

Resellers & Partners

Contact

STAHLWERK ARC 200 MD Digital welding machine with 200 amps | fully equipped | welding helmet | electrodes | equipment trolley | DC MMA/E-Hand | Lift-TIG | digital display | ARC-Force | VRD | smart cooling

Functions

Features & benefits

Technical Data

Artikel

Model	STAHLWERK ARC 200 MD Digital
Process	MMA / E-hand, optional DC-Lift-TIG
Output current MMA	10-200 A
MMA duty cycle (40 °C)
	10 % at 200 A
	60 % at 82 A
	100 % at 63 A
Mains voltage	1 x 230 V AC (±15 %)
Mains frequency	50 / 60 Hz
Max. Mains current (I₁max)	MMA 40 A, WIG 28 A
Maximum effective mains current (I₁eff)	MMA 12.6 A, WIG 8.8 A
Protection class	IP21S
Dimensions (L x W x H)	269 x 116 x 187 mm
weight	approx. 3.4 kg
Mains connection	CEE 7/7 Schuko plug
Standards	IEC 60974-1; EN 60974-10 (Class A)
Certified by	SGS Standards Technical Services Co, Ltd.
WEEE reg. no. DE	85577200
